Specifications(d/mm) | Tip Radius | Shank Diameter | Overall Length | Number of Flutes |
R0.5*4D*50L*2T | 0.5 | 4 | 50 | 2 |
R0.75*4D*50L*2T | 0.75 | 4 | 50 | 2 |
R1*4D*50L*2T | 1 | 4 | 50 | 2 |
R1.25*4D*50L*2T | 1.25 | 4 | 50 | 2 |
R1.5*3D*50L*2T | 1.5 | 3 | 50 | 2 |
R1.5*4D*50L*2T | 1.5 | 4 | 50 | 2 |
R1.75*4D*50L*2T | 1.75 | 4 | 50 | 2 |
R2*4D*50L*2T | 2 | 4 | 50 | 2 |
R3*6D*50L*2T | 3 | 6 | 50 | 2 |
R3*6D*75L*2T | 3 | 6 | 75 | 2 |
R3*6D*100L*2T | 3 | 6 | 100 | 2 |
R4*8D*60L*2T | 4 | 8 | 60 | 2 |
R4*8D*75L*2T | 4 | 8 | 75 | 2 |
R5*10D*75L*2T | 5 | 10 | 75 | 2 |
R5*10D*100L*2T | 5 | 10 | 100 | 2 |
R6*12D*75L*2T | 6 | 12 | 75 | 2 |
R6*12D*100L*2T | 6 | 12 | 100 | 2 |
R7*14D*100L*2T | 7 | 14 | 100 | 2 |
R8*16D*100L*2T | 8 | 16 | 100 | 2 |
R9*18D*100L*2T | 9 | 18 | 100 | 2 |
R10*20D*100L*2T | 10 | 20 | 100 | 2 |
1. Double-Flute Design
Stable in cutting and chip removal, and with excellent wear resistance for consistent performance.
2. Sharp and Durable with Smooth Chip Evacuation
Reduces the number of tool changes, improves efficiency, and saves production time.
3. Fully Ground Cutting Edge with Nano Composite Coating
High temperature resistant, corrosion-resistant, and highly wear-resistant, effectively enhancing the tool's hardness and service life.
Specifications(d/mm) | Tip Radius | Shank Diameter | Overall Length | Number of Flutes |
R0.5*4D*50L*2T | 0.5 | 4 | 50 | 2 |
R0.75*4D*50L*2T | 0.75 | 4 | 50 | 2 |
R1*4D*50L*2T | 1 | 4 | 50 | 2 |
R1.25*4D*50L*2T | 1.25 | 4 | 50 | 2 |
R1.5*3D*50L*2T | 1.5 | 3 | 50 | 2 |
R1.5*4D*50L*2T | 1.5 | 4 | 50 | 2 |
R1.75*4D*50L*2T | 1.75 | 4 | 50 | 2 |
R2*4D*50L*2T | 2 | 4 | 50 | 2 |
R3*6D*50L*2T | 3 | 6 | 50 | 2 |
R3*6D*75L*2T | 3 | 6 | 75 | 2 |
R3*6D*100L*2T | 3 | 6 | 100 | 2 |
R4*8D*60L*2T | 4 | 8 | 60 | 2 |
R4*8D*75L*2T | 4 | 8 | 75 | 2 |
R5*10D*75L*2T | 5 | 10 | 75 | 2 |
R5*10D*100L*2T | 5 | 10 | 100 | 2 |
R6*12D*75L*2T | 6 | 12 | 75 | 2 |
R6*12D*100L*2T | 6 | 12 | 100 | 2 |
R7*14D*100L*2T | 7 | 14 | 100 | 2 |
R8*16D*100L*2T | 8 | 16 | 100 | 2 |
R9*18D*100L*2T | 9 | 18 | 100 | 2 |
R10*20D*100L*2T | 10 | 20 | 100 | 2 |
1. Double-Flute Design
Stable in cutting and chip removal, and with excellent wear resistance for consistent performance.
2. Sharp and Durable with Smooth Chip Evacuation
Reduces the number of tool changes, improves efficiency, and saves production time.
3. Fully Ground Cutting Edge with Nano Composite Coating
High temperature resistant, corrosion-resistant, and highly wear-resistant, effectively enhancing the tool's hardness and service life.
